PIR PCR Thermoplastic Elastomers (TPEs)
PHOENIX™ PIR PCR Thermoplastic Elastomers contain scrap generated within the material extruders facility, from the post-industrial recycled content, as well as post-consumer/pre-consumer recycled content. This product family utilizes fully the wastes generated from the industry or after-consumer market and cuts the carbon footprint to make the material more environmentally friendly and sustainable. Materials are available in black or dark colors. Opaque is also available on request.
- Product Series
- PHOENIX™ TPE 10 Series (Shore 30A ~ 90A)
Contain Post-Industrial Recycle (PIR) content. Sustainable, cut carbon footprint
- Features
- Wide range hardness (Shore 30A ~ 90A)
Anti-slip
Non-sticky
Easy to process
Overmolding to PP
Energy saving
Cut carbon footprint
- Applications
- screwdriver grip, garden tool grip, knife grip, car mat, sink plug, etc.
- Safety/Quality Approvals
- RoHS, EN71, REACH SVHC, PAHS & phthalate, Formaldehyde, Dimethyl Fumarate, Nonylphenol
| ITEM | Color | Hardness | Specific Gravity | Tensile Strength | 100% Tensile Modulus | Elongation at Break | Tear Strength |
|---|---|---|---|---|---|---|---|
| ASTM D2240 | ASTM D792 | ASTM D412 | ASTM D412 | ASTM D412 | ASTM D624 Die C | ||
| Shore A/D | g/cm3 | psi | psi | % | lbs/in | ||
| 10301 | Black | 30±3 A | 1.18±0.03 | 289 | 79.7 | 889.8 | 58.2 |
| 10401 | Black | 45±3 A | 1.17±0.03 | 359.2 | 111.1 | 831 | 74.5 |
| 10403 | Black | 58±3 A | 1.2±0.03 | 368.8 | 124.4 | 766.8 | 68.5 |
| 10451 | Black | 45±3 A | 1.15±0.03 | 312.5 | 129.5 | 657.1 | 73.5 |
| 10501 | Black | 50±3 A | 1.19±0.03 | 324.5 | 119.5 | 785.2 | 64.7 |
| 10601 | Black | 60±3 A | 1.14±0.03 | 537.9 | 202.4 | 715.1 | 108.2 |
| 10602 | Black | 60±3 A | 1.14±0.03 | 546 | 205.7 | 723.4 | 110.4 |
| 10701 | Black | 70±3 A | 1.14±0.03 | 513 | 313.6 | 550.5 | 130.6 |
| 10801 | Black | 80±3 A | 1.13±0.03 | 629.4 | 446.9 | 507.4 | 164.6 |
| 10851 | Black | 90±3 A | 1.08±0.03 | 617.2 | 564.6 | 232.8 | 156.6 |
| 10901 | Black | 90±3 A | 1.08±0.03 | 965.2 | 828 | 397.3 | 258.8 |
